Key Selling Points
1. Instant Dimming & High Definition
- Rapid Response Time: The RLM 1100 features instant dimming, reacting to light changes in less than 1/10,000 seconds. This ensures quick transitions between light and dark modes, providing immediate protection against arc flashes and harmful radiation.
- High-Definition Vision: Equipped with a high-definition lens system, the Auto-Darkening Welding Helmet provides clear and sharp images, allowing welders to see finer details crucial for producing high-quality welds.
2. Optical Clarity with Liquid Crystal Filter
- Superior Optical Class Rating: The Auto-Darkening Welding Helmet offers an optical class rating of 1/1/1/2, ensuring minimal distortion and providing an evenly darkened viewing area, which helps welders work with more precision.
- Advanced Liquid Crystal Filter: The liquid crystal filter maintains consistent darkening across the entire lens, reducing eye fatigue and enhancing comfort during extended work sessions.
3. True Color Lens Technology
- Natural Color Perception: The True Color Lens Technology provides a more accurate view of the welding environment, reducing color distortion and allowing welders to distinguish between different materials easily.
- Enhanced Detail Recognition: This technology improves visibility of fine details, which helps to achieve precise welds and enhances overall work quality.
4. Adjustable Shade and Light Control
- Customizable Shade Range: The Auto-Darkening Welding Helmet offers a light state of DIN 4 and a dark state range adjustable between DIN 9 and DIN 13, making it suitable for various welding processes, including TIG, MIG, and stick welding.
- Integrated Control Panel: The integrated panel allows for quick adjustment of light sensitivity and shade levels, providing flexibility for different tasks and environments.
Contact Us
Product Features
1. Solar-Powered Operation with Battery Backup
- Solar Panel Integration: The RLM 1100 features a solar panel that extends battery life, reducing the need for frequent replacements and enhancing energy efficiency.
- Low Battery Indicator: A power indicator alerts users when the lithium battery is low, ensuring continuous operation without unexpected power failures.
2. UV/IR Protection
- Permanent UV/IR Protection: The Auto-Darkening Welding Helmet provides ongoing protection from harmful ultraviolet and infrared radiation, even when the auto-darkening filter is inactive, safeguarding the welder’s eyes at all times.
- Enhanced Safety: This feature ensures consistent eye protection, whether welding or grinding.
3. Grind Mode for Versatility
- Welding and Grinding Compatibility: The built-in grind mode allows for easy transitions between welding and grinding tasks without changing equipment.
- Fixed Shade in Grind Mode: The Auto-Darkening Welding Helmet maintains clear visibility during grinding by preventing sudden changes in lens shade.
4. Versatile Lens Compatibility
- Multiple Lens Options: Compatible with RL500H, RL500J, and RL500LS lenses, the RLM 1100 offers options for various viewing areas.
- Durable Lenses: These lenses are heat and impact resistant, ensuring long-term durability in tough environments.
5. Auto-Darkening and Adjustable Sensitivity
- Customizable Settings: Welders can adjust the sensitivity and delay of the auto-darkening filter to suit different lighting conditions and arc intensities.
6.Certifications and Comfort
- Meets ANSI Z87.1, CSA Z94.3, and CE Certified: The Auto-Darkening Welding Helmet ensures high safety standards.
- Lightweight and Adjustable Headgear: Designed for comfort, the Auto-Darkening Welding Helmet is lightweight, with adjustable headgear for prolonged wear without discomfort.
| RL-500H |    |
| RL-500J |    |
| RL-500LS |    |
RL500H RL500J RL500LS
93*43mm/100*50mm
| Type | RL-500H | RL-500J | RL-500LS |
| Optical Class | 1/1/1/2 | 1/1/1/2 | 1/1/1/2 |
| Filter Size (mm) | 110x90x9 | 110x90x9 | 110x90x9 |
| Active Viewing Area (mm) | 93x43 | 93x43 | 100x50 |
| Light Shade | DIN4 | DIN4 | DIN4 |
| Dark Shade | DIN9~13 | DIN9~13 | DIN9~13 |
| Shade Control | External Variable | External Variable | External Variable |
| Switching Time | 0.3ms | 0.3ms | 0.3ms |
| Sensitivity Adjustment | Stepless Control | Stepless Control | Stepless Control |
| Delay Time | 0.1S~0.8S | 0.1S~0.8S | 0.1S-0.8S |
| Power Supply | Li-battery&Solar | Li-battery&Solar | Li-battery&Solar |
| Rated Capacity of Li-battery | 200mAh | 600mAh | 200mAhx2 |
| Replaceable battery | YES | YES | YES |
| Operating Temperature | -5℃~55℃ | -5℃~55℃ | -5℃~55℃ |
| Arc Sensor | 2 | 2 | 4 |
| UV/lR Protection | DIN16 | DIN16 | DIN16 |
| Low Volume Alarm | No | YES | YES |
| Grind Functinon | YES | YES | YEs |
| CUT | No | No | No |
| CE | YES | YES | YES |
| True colour | NO | YES | YES |
| Mask Material | PP | PP | PP |
| RL-500 |     |
| RL-500L |    |
RL-500, RL-500L
| Type | RL-500 | RL-500L |
| Optical Class | 1/1/1/2 | 1/1/1/2 |
| Filter Size (mm) | 110x90x9 | 110x90x9 |
| Active Viewing Area (mm) | 90x35 | 100x50 |
| Light Shade | DIN3 | DIN 4 |
| Dark Shade | DIN11 | DIN9-13 |
| Shade Control | No | External Variable |
| Switching Time | 0.3ms | 0.3ms |
| Sensitivity Adjustment | No | Stepless Control |
| Delay Time | 0.2S | 0.1S~0.8S |
| Power Supply | Li-battery&Solar | Li-battery&Solar |
| Rated Capacity of Li-battery | 200mAh | 200mAh |
| Replaceable battery | YES | YES |
| Operating Temperature | -5℃~55℃ | -5℃~55℃ |
| Arc Sensor | 2 | 4 |
| UV/lR Protection | DIN16 | DIN16 |
| Low Volume Alarm | No | No |
| Grind Functinon | No | YES |
| CUT | No | No |
| CE | YES | YES |
| True colour | No | YES |
| Mask Material | PP | PP |
Model: RLM 700
Model: RLM 1000
Model: RLM 1100
Model: RLM 800
Model: RLM 900
Model: RLM 1200
